Shure ULXD4-H50 Single ULX-D Wireless Receiver with 1/2 Wave Antennas

Name: Shure ULXD4-H50 Single ULX-D Wireless Receiver with 1/2 Wave Antennas
SKU: ULXD4-H50
Availability: PreOrder
Rating: 5.00 (1 reviews)

Rated 5.00 out of 5 based on 1 customer rating

(1 customer review)

Main view of the Shure ULXD4-H50 Single ULX-D

Shure ULXD4-H50 Single ULX-D Wireless Receiver features audio and RF meters, 60 dB of gain control, and both XLR and 1/4″ outputs. A large LCD screen and intuitive controls let you quickly make adjustments, even in low-light situations.

$1,519.00

Available on backorder

UPC: 42406338998UPC: 42406338998

Tags: Audio Channels Diversity Antenna SHURE Single-Channel ULXD Wireless ReceiverCategory: ReceiversSKU: ULXD4-H50

Features of the Shure ULXD4-H50 Single ULX-D Wireless Receiver with 1/2 Wave Antennas:

For Large Venues & A/V Installations
1 x Digital Audio Channel, 1/2 Rackspace
64 MHz Tuning Range
Expandable up to 60 Channels
1 x Ethernet Port
Secure AES-256 Encryption

Specifications:

Receiver
Receiver Type Tabletop
Mounting Options Rackmount, Tabletop (with Included Hardware)
Rackmount Size 1 RU (1/2 Rack)
Antenna 2 x 1/2 Wave External, BNC (Rear-Mount)
Antenna Bias Voltage 12 to 13 VDC, 150 mA (per Antenna)
Number of Audio Channels 1
Audio I/O 1 x XLR 3-Pin Male Balanced Output
1 x 1/4″ TRS Female Balanced Output
Gain Range -18 to +42 dB (1 dB Steps)
Pad 30 dB
Audio Output Level XLR Output:
+18 dBV (Line Level)
XLR Output:
-12 dBV (Mic Level)
1/4″ Output:
+12 dBV (Consumer Level, Instrument Level)
Phantom Power Protection On 1/4″, XLR Outputs
Frequency Response 30 Hz to 20 kHz ±1 dB (Dependent on Mic)
Network I/O 1 x RJ45 (10/100 Mb/s)
Network Protocols DHCP, Manual IP
Impedance XLR Output:
100 Ohms (Balanced)
Approximate RF Sensitivity -98 dBm
Adjacent Channel Isolation >70 dB
Spurious Rejection: >80 dB
Power Requirements AC/DC Power Adapter
AC/DC Power Adapter 15 VDC at 600 mA (Included)
AC Input Power 100 to 240 VAC, 50 / 60 Hz at 250 mA
Display & Indicators 1 x Backlit LCD (Battery Status, Channel, Group, Menu Navigation)
2 x Multi-Segment LED (AF Level, Output Level, Peak)
Housing Steel
Operating Temperature 0 to 122°F / -17 to 50°C
Storage Temperature -20 to 165°F / -28 to 73°C
Dimensions 6.7 x 1.7 x 7.8″ / 171 x 44 x 197 mm
Weight 2 lb / 0.9 kg
Microphone
Wireless Technology Digital UHF
Number of RF Channel Frequencies 2560
Diversity Antenna Diversity
RF Frequency Band H50:
534 to 598 MHz
RF Bandwidth 64 MHz
Frequency Step Size 25 kHz
RF Channel Scanning Auto-Scan
Max Operating Range 328.1′ / 100 m
Max Transmitters per Band 60
Latency < 2.9 ms
Modulation Proprietary
