ADJ Allegro Z6 – Quick moving linear fixture with 6 lenses

(1 customer review)

GTR Direct Canada's choice for DJ gear

$2,299.00

UPC: 818651026870 SKU: ALL026 Category: Tag:
ADJ lighting solutions Canada

The ADJ Allegro Z6 is a linear fixture that features 6 lenses, motorized zoom and motorized tilt (220-degrees) on the X axis.

It’s powered by six 30W Quad (4-IN-1) RGBW LEDs. Each LED’s color may be controlled individually.

The fixture’s beam angle is adjustable between 4-degrees and 32-degrees. It has a 4-button function display, 5-pin DMX In/Out to link data and locking power connectors to daisy chain power. The fixture also has RJ45 In/Out connections for Art-Net and Kling-Net control. There is a convenient USB input for updating the fixture’s firmware.
The Allegro Z6 is a powerful and versatile fixture ideal for use on concert stages and on touring productions as well as for permanent installation in large nightclubs and other entertainment venues.

Specifications

Light Source:

• LED: 6x 40W QUAD (4-In-1) RGBW LEDs (30,000 hr.)

• Motorized Zoom: 4° ~ 32°

• LUX: 47,000 @ 2M, Zoomed in to 4°; 1,900 @ 2M, Zoomed out to 32°

Features:

• Motorized Zoom

• Tilt Lock for stable transporting

• USB Input for Updating Fixture Firmware

• Folding carrying handle

• Rubber feet so fixture can be set on the ground

• All metal construction with black housing

• Includes 2 Omega brackets for mounting to truss

• Flicker Free, 1200Hz PWM frequency

• Linear variable white temperature control

Construction:

• Display: OLED display with function buttons

• 5-pin DMX In/Out for data linking

• RJ45 In/Out for Art-Net & Kling-Net control

• Locking power In/Out to daisy chain up to 6 fixtures (@ 120V), 11 fixtures (@ 230V)

Control:

• Control Modes: DMX512, RDM, Art-Net & Kling-Net

• Multiple DMX channel modes

• Tilt & Tilt Fine: 220°

• Strobe & Pulse Effects

• 6 individually controlled Pixels

• 0-100% Dimming + 16-bit Fine Dimming

• 6 Preset Dim Curve Modes plus Dim Speed control

• With Wired Digital Communication Network

Electrical:

• Power voltage: AC100-240V, 50/60Hz (Multi-voltage)

• Power consumption: 240W max

Dimensions & Weight:

• Dimension (LxWxH): 19.6” x 4.5” x 11” / 500x113x278mm

• Weight: 22 lbs. / 10kg.

What’s Included:

• Two Omega Brackets

• Locking power cord

Approvals:

ETL Approved



Brand

American DJ

ADJ is known for reliable products, exceptional customer support and innovation, having recently pioneered a number of market-leading IP65-rated lighting solutions. The company’s range includes moving head luminaires, static washes, beam effects, audience blinders, strobes, DMX control hardware/software, LED video panels and related accessories, as well as fog, haze and other atmospheric effect generators. ADJ serves both the AVL rental and installation markets. Its products are used worldwide for events, productions and festivals of all sizes, and are also installed in a wide variety of venues ranging from churches, and theatres to trampoline parks and roller rinks, nightclubs and lounges to concert venues and event centers.

The ADJ family of brands include: ADJ Lighting, Elation Professional, Avante Audio, American Audio, Acclaim Lighting, Magmatic Effects, Obsidian Control Systems, Eliminator Lighting, Global Truss America, DuraTruss, Accu-Cable and Accu-Stand.
