ADJ Encore FR Pro Color Grade 7″ LED Fresnel Fixture
ADJ Encore FR Pro Color Grade 7″ LED Fresnel Fixture is a professional grade Fresnel fixture with a 7-inch lens powered by a 400W 6-IN-1 LED engine with red, green, blue, amber, lime and cyan LEDs.
$2,039.00
Features of the ADJ Encore FR Pro Color Grade 7″ LED Fresnel Fixture:
- 400W 6-in-1 LED Engine (Red, Green, Blue, Amber, Lime, Cyan.)
- Virtual CMY color mixing DMX control modes.
- Tunable white color temperature from 2400k to 8500k.
- Adjustable refresh rate (68 presets from 900 – 25,000 Hz.)
- 6 preset dim modes.
- 60 preset colors on virtual color wheel.
- 64 preset RGBA color macros.
- Motorized Zoom (Beam angle 7° – 44°.)
Specifications:
SOURCE
400W 6-IN-1 LED (Red, Green, Blue, Amber, Lime and Cyan)
50,000 Hour Average LED Life*
*May vary depending on several factors including but not limited to:
Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control and Dimming.
PHOTOMETRIC DATA
11,384 Total Lumen Output (Full ON, Zoomed Out to Full)
28,670 LUX 2,664 FC @6.6’ (2m) (Zoomed In / Full ON)
3,638 LUX 338 FC @6.6’ (2m) (Zoom Out / Full ON)
Beam Angle: 8° to 56°
Max Field Angle: 70°
Color Temperature: Tunable, 2400K to 8500K
CRI: 94+
EFFECTS
Motorized Zoom
Electronic Dimmer and Strobe (1-20Hz)
Variable 16-bit Dimming Modes and Curves
Virtual CMY Color Mixing DMX Control Modes
Tunable White Color Temperature from 2400K to 8500K
62 Preset White Color Temp Macros (2400K to 8500K)
60 Preset Colors on Virtual Color Wheel
64 Preset RGBA Color Macros
CONTROL / CONNECTIONS
Manual and DMX Controlled Dimmer and Shutter
Dimmer and Zoom Rotary Dials
(5) DMX Channel Modes (14 / 17 / 19 / 13 CMY / 19 CMY)
Adjustable Refresh Rate (68 presets from 900 – 25,000Hz)
6 Preset Dim Modes (Standard, Stage, TV, Architectural, Theatre and Stage 2)
Dim Speed Options (0.1s to 10s)
4 Dim Curves (Square, Linear, Inv. Squa and S. Curve)
4 Button Control Panel LCD Menu Display
RDM (Remote Device Management)
3/5pin DMX Input and Output
Locking Power Input and Output
USB Service Port
With Wired Digital Communication Network
SIZE / WEIGHT
Length: 16.32” (414.5mm)
Width: 14.18” (360.1mm)
Vertical Height: 19.29” (490mm)
Weight: 20.9 lbs. (9.45kg)
ELECTRICAL / THERMAL
AC 100-240V – 50/60Hz
450W Max Power Consumption
5°F to 113°F (-15°C to 45°C)
Power Linking: 2Pcs @ 110V / 5Pcs @ 240V
INCLUDED ITEMS
Gel Frame
Locking Power Cable
OPTIONAL ACCESSORIES
Barn Doors
APPROVALS / RATINGS
CE | cETLus | IP20
