ADJ Jolt Bar FX Linear LED Wash/Strobe/Blinder (RGBW)

(1 customer review)

ADJ Jolt Bar FX Linear LED Wash/Strobe/Blinder (RGBW) ideal for concert productions, festival stages, and rental houses, as well as for permanent installation in large nightclubs. The fixture features 672 RGB LEDs and 112 CW LEDs that can generate intense white strobing and color-chase effects.


SKU: 810087370220 Category: Tags:
ADJ lighting solutions Canada

Features of the ADJ Jolt Bar FX Linear LED Wash/Strobe/Blinder (RGBW):

  • 672 RGB and 112 Cool White SMD LEDs
  • 32 RGB LED Zones, 16 White LED Zones
  • Use as Strobe, Blinder, or Color Wash
  • Several DMX Channel Modes
  • 5-Pin DMX Input and Output
  • Dimming Modes and Speed Control
  • Color Macros and Programs
  • Adjustable Strobe and LED Refresh Rate
  • Includes Two Integrated Hanging Brackets
  • Includes Locking Power Cord

Lighting Type Blinder / Effects / Strip/Bar Light
Light Source 672 x Color LED (SMD) – 0.3 W
112 x White LED (SMD) – 5 W
Light Source Life Expectancy 50,000 Hours
Colors Red
Cool White
Pixel Configuration 48 x Zones
Color Temperature 4600 to 7000K
Beam Angle 116°
Shutter / Strobe Electronic
Dimming Electronic, 0 to 100% with 6 Dimmer Modes
Operating Modes Automatic, Color Change, DMX, Program
Macros / Programs 25 x Auto-Program
Effects Strobe
Strobe Rate 0.3 to 25 Hz
Gobos None
PWM Frequency 900 Hz to 25 kHz (Adjustable)
Control Protocols DMX512
DMX Channel Modes 11 Mode(s):
6 / 9 / 13 / 16a / 18 / 32 / 38 / 42a / 64 / 112 / 126-Channel
Remote Control None
Display / Controls LCD / 4-Button
I/O 1 x XLR 5-Pin DMX Input
1 x XLR 5-Pin DMX Output
1 x USB Type-A Service Input/Output
AC Input Power 100 to 240 VAC, 50/60 Hz
AC Power Connector Input: powerCON
Output: powerCON
Power / Current Consumption 340 W (Max)
IP Rating None
Mounting Floor Stand, Mounting Bracket, Single Yoke
Duty Cycle None
Exterior Color Black
Dimensions 39.4 x 4.1 x 4.4″ / 100.1 x 10.4 x 11.2 cm
Weight 8.8 lb / 4 kg


American DJ

ADJ is known for reliable products, exceptional customer support and innovation, having recently pioneered a number of market-leading IP65-rated lighting solutions. The company’s range includes moving head luminaires, static washes, beam effects, audience blinders, strobes, DMX control hardware/software, LED video panels and related accessories, as well as fog, haze and other atmospheric effect generators. ADJ serves both the AVL rental and installation markets. Its products are used worldwide for events, productions and festivals of all sizes, and are also installed in a wide variety of venues ranging from churches, and theatres to trampoline parks and roller rinks, nightclubs and lounges to concert venues and event centers.

The ADJ family of brands include: ADJ Lighting, Elation Professional, Avante Audio, American Audio, Acclaim Lighting, Magmatic Effects, Obsidian Control Systems, Eliminator Lighting, Global Truss America, DuraTruss, Accu-Cable and Accu-Stand.
