Elation ACL 360i 60W RGBW Moving Head Beam Light

(1 customer review)

$1,269.00

UPC: 837874019438 SKU: 837874019438 Category: Tags:
Elation

Elation ACL 360i 60W RGBW Moving Head Beam Light

The Elation ACL 360i 60W is an amazing single beam moving effect luminaire featuring a single 60W RGBW 4-in-1 LED and the new advanced collimator optic lens, which produces a laser-like homogenized 4° color-changing beam. Features 10 and 45 degree frost lens options (included), fast and precise 16-bit continuous full 360° pan and tilt rotation, strobe, and selectable dimming curve effects, DMX, RDM (Remote Device Management), KlingNET™ and Art-NET support, 5pin XLR, powerCON, and RJ45 ethernet in/out connections, (6) button control full color 180° reversible menu display, 110W max power consumption, and a multi-voltage universal auto switching power supply (100-240v).

Specifications

Features

  • Amazing 4° Single Beam Moving Effect Luminaire
  • New Advanced Collimator Optic Lens
  • 60W RGBW 4-in-1 LED
  • Laser-Like Homogenized Color Changing Beam
  • 10° and 45° Frost Lens Options Included
  • Fast and Precise 16-Bit Continuous 360° Pan/Tilt Rotation
  • Strobe and Selectable Dimming Curve Effects
  • RDM, KlingNET™ and Art-NET (DMX Over Ethernet)
  • Flicker Free Operation for Broadcast TV and FILM

SOURCE

  • 60W RGBW 4-in-1 LED
  • 100,000 Hour Average LED Life*
  • *LED Life may vary depending on several factors including but not limited to:
  • Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.

PHOTOMETRIC DATA

  • 30,601 LUX 2,843 FC @6.6’ (2m)
  • 12,955 LUX 1,204 FC @9.8’ (3m)
  • 7,687 LUX 714 FC @13.1’ (4m)
  • 5,112 LUX 475 FC @16.4’ (5m)

EFFECTS

  • Strobe and Selectable Dimming Curves
  • Color Macros

COLOR

  • RGBW

CONTROL / CONNECTIONS

  • (3) DMX Channel Modes (16 / 18 / 20)
  • RDM (Remote Device Management)
  • 6 Button Touch Control Panel
  • Full Color 180° Reversible LCD Menu Display
  • 8 / 16 Bit Resolution Adjustable Movement
  • 5pin DMX In/Out
  • RJ45 Ethernet In/Out (KlingNET™ / Art-NET)
  • powerCON Power In/Out

SIZE / WEIGHT

  • Length: 8.7” (222mm)
  • Width: 7.3” (186mm)
  • Vertical Height: 13.0” (330mm)
  • Weight: 11.5 lbs. (5.2 kg)

ELECTRICAL / THERMAL

  • AC 100-240V – 50/60Hz
  • 110W Max Power Consumption
  • 5F to 113°F (-15°C to 45°C)

APPROVALS / RATINGS

  • CE | cETLus | IP30

INCLUDED ITEMS

  • 10° Frost Lens
  • 45° Frost Lens
  • Omega Bracket
  • powerCON Cable
