Elation KL Fresnel 8 FC RGBMA Light w/ Motorized Zoom

(1 customer review)

The Elation KL Fresnel 8 FC is a full-color-spectrum LED fixture that provides high output, precise color temperature control, full spectrum color rendering and even wash coverage.
Optimized for the tunable white light requirements of Film and Television.


UPC: 810008262481 SKU: KL-FRESNEL-8-FC Category: Tags:

Features of the Elation KL Fresnel 8 FC:

  • RGBMA LED EngineDynamic White + Full Spectrum Color Control
  • 18,000 Total Fixture Lumen Output
  • 10° to 50° Wide Motorized Zoom
  • Stand-Alone control with 2 Encoders and LED Display
  • Smooth 16-bit Selectable Dimming Modes and Curves
  • LED Refresh Rate Adjustment
  • Flicker Free Operation for TV and FILM
  • RDM (Remote Device Management)
  • 8-leaf Barn Doors, Gel Frame and Junior Pin (1 1/8” – 28mm) included



  • 6500K RGBMA LED Engine
  • 50,000 Hour Average LED Life*

*May vary depending on several factors including but not limited to:
Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control and Dimming.


  • 18,000 Total Lumen OutputCRI 94.5
  • TLCI 94
  • Zoom Range 10° – 50°
  • Beam Angle 10.4° – 50.8°
  • Field Angle 20.6° – 66.1°


  • Motorized Zoom
  • Electronic Dimmer and Strobe
  • Variable 16-bit Dimming Modes and Curves


  • RGBMA Color Array
  • CMY Emulation
  • Variable CCT 2,400K – 8,500K
  • Green/Magenta Shift
  • Virtual Gel Swatch Book


  • 6 DMX Channel Modes (1 to 18 channels)
  • Manual and DMX Controlled Dimmer, Color and Zoom
  • Dual Rotary Dials
  • 4 Button Control Panel, LED Display
  • RDM (Remote Device Management)
  • 3/5pin DMX and IP65 Locking Power In/Out Connection


  • Length: 15.1” (382.5mm)
  • Width: 12.9” (326.5mm)
  • Vertical Height: 17.9” (455mm)
  • Weight: 23.15 lbs. (10.5kg)


  • AC 100-240V – 50/60Hz
  • 514W Max Power Consumption
  • 5°F to 113°F (-15°C to 45°C)
  • BTU/hr (+/- 10%) 1752.74


  • Gel Frame and Rotating 8-leaf Barn Doors
  • Junior Pin (1 1/8″  – 28mm)
  • IP65 Locking Power Cable
