Furman PL-PRO DMC 20 Amp Power Conditioner with Lights, Volt/Ammeter
The Furman PL-PRO DMC 20 Amp Power Conditioner with Lights, Volt/Ammeter features Furman’s revolutionary Series Multi-Stage Protection (SMP), Linear Filtering Technology (LiFT), and Extreme Voltage Shutdown (EVS). Together, these technologies comprise what is, without question, one of the world’s most advanced and comprehensive transient voltage surge suppressors.
Features of the Furman PL-PRO DMC 20 Amp Power Conditioner with Lights, Volt/Ammeter:
- Surge Protection
- Furman’s exclusive SMP technology provides the highest level of surge & spike protection available.
- Noise Filtration
- LiFT offers AC power filtering to ensure clean power for unequaled audio & video clarity.
- Voltage Protection
- Advanced EVS circuitry detects dangerous voltage irregularities and safely powers down itself and connected equipment in unsafe conditions.
- Pull-out Lights
- Dual smooth track retractable LED lights illuminate equipment in your rack.
- Diagnostic Lights
- LED status indicators warn you when voltage is outside of nominal range or when protection has been compromised.
- USB Charger
- Front panel convenience charger allows you to charge most media devices or power a USB lamp.
- Voltmeter / Ammeter
- Large digital voltmeter / ammeter, with discrete dimmer button, displays line votlage and true RMS current draw.
- Isolated Banks
- Isolated outlet banks minimize inter-component interference and noise contamination.
- Wall Wart Spacing
- Three widely spaced outlets accommodate bulky AC power transformers.
- 20 AMP Rating
- 20 Amp rating featuring a high inrush magnetic circuit breaker for added protection.
- Nine Total Outlets
- Nine total outlets (8 rear panel outlets and one front panel convenience outlet).
- BNC Lamp Connector
- Rear panel BNC connector powers any standard gooseneck lamp for rear rack illumination.
- Family Classic Series
- Line Voltage 120 (Volts)
- Number of Outlets 9
- Number of Isolated Banks 2
- Outlet Descriptions All 9 outlets linearly filtered and surge protected
- Rack Mountable Yes
- Rack Ears Included Yes
- Front Panel Meter(s) LED voltmeter/ammeter displays incoming voltage and true RMS current draw
- Front Media Light(s) 2 multi-LED, dimmable lamps
- Control Front panel:
– On/Off switch
– Voltage meter dimmer button
- Voltage Regulation No
- Compliances TUV us
- USB Charging 1 front panel USB charger
- Low Voltage Trigger N/A
- AC Power Cord 10 ft., captive 3/12 AWG, with NEMA 20 plug
- Dimensions19″ W x 10.5″ D x 1.75″ H
- Weight 12 lbs
- Power Consumption 12 Watts
- AC Protection Technology Extreme Voltage Shutdown
Series Multi-Stage Protection
Non-sacrificial protection with zero ground contamination
- Under-Voltage Shutoff 90V
- Over-Voltage Shutoff 140 VAC
- Maximum Current Rating 20 (Amps)
- Initial Clamping Level 188 VAC peak @ 3,000 Amps
- Filtration Technology LiFT
- Filtration Rating 10 dB @ 10 kHz
40 dB @ 100 kHz
50 dB @ 500 kHz
- Signal Line Protection No
- Response Time: 1 nanosecond
- Maximum Surge Current: 6,500 amps
- Construction: Steel chassis, .120″ brushed and black anodized aluminum front panel; glass epoxy printed circuit boards
- Master Pack Qty2
|Dimensions||21.5 × 15.2 × 4.2 in|
