RCF NX 15-SMA 15″ Woofer 130 DB MAX SPL

(1 customer review)

The RCF NX 15-SMA 15″ Woofer 130 DB MAX SPL is equipped with new high power 700 W digital amplifier and a newly designed 15” coaxial neodymium transducer that guarantees outstanding audio quality and definition as well as an extremely lightweight of the final system.

$3,714.00

UPC: 8024530009045 SKU: RCF-NX 15 SMA Category: Tags:
RCF Canada

Features of the RCF NX 15-SMA 15″ Woofer 130 DB MAX SPL :

  • 1400 Watt Peak, 700 Watt RMS digital bi-amplification
  •  130 dB max spl
  •  60° x 60° constant directivity horn
  •  15″ High power neodymium woofer, 2.5″ voice coil
  •  1.7″ kapton dome, 1″ exit, neodymium high frequency driver
  •  DSP processing, floor – free field equalization, soft limiter and protection
  •  Combo xlr/jack input, xlr signal output
Specifications

Acoustical specifications
FREQUENCY RESPONSE:
50 Hz ÷ 20000 Hz

MAX SPL @ 1M:
130 dB

HORIZONTAL COVERAGE ANGLE:
60°

VERTICAL COVERAGE ANGLE:
60°
Transducers
COMPRESSION DRIVER:
Coaxial 1.0” neo, 1.75” v.c

WOOFER:
Coaxial 15” neo, 2.5” v.c
Input/Output section
INPUT SIGNAL:
bal/unbal

INPUT CONNECTORS:
XRL, Jack

OUTPUT CONNECTORS:
XLR

INPUT SENSITIVITY:
+4 dBu
Processor section
CROSSOVER FREQUENCIES:
1700 Hz

PROTECTIONS:
RMS, HF

LIMITER:
Soft Limiter

CONTROLS:
Freefield, floor
Power section
TOTAL POWER:
1400 W Peak, 700 W RMS

HIGH FREQUENCIES:
400 W Peak, 200 W RMS

LOW FREQUENCIES:
1000 W Peak, 500 W RMS

COOLING:
Convection

CONNECTIONS:
Powercon IN/OUT
Standard compliance
CE MARKING:
Yes
Physical specifications
CABINET/CASE MATERIAL:
Baltic birch plywood

HANDLES:
1 on side

POLE MOUNT/CAP:
Yes

GRILLE:
Steel

COLOR:
Black
Size
HEIGHT:
362 mm / 14.25 inches

WIDTH:
650 mm / 25.59 inches

DEPTH:
468 mm / 18.43 inches

WEIGHT:
20.2 kg / 44.53 lbs

Brand

RCF

SINCE 1949 RCF BEGAN PRODUCING TRANSDUCERS IN 1949.
The first products sold were microphones and loudspeakers. In the late ’60s, concert sound was going electric, and many loudspeaker pioneers were searching for high-powered devices to use in their designs. RCF was one of the first European OEM suppliers for international brands, thanks to the company’s experience gained building high power transducers. In-depth know-how in transducers and electronics provided the perfect technological culture to allow RCF to develop complete pro audio systems, bringing the company to a leading position in multiple audio markets over the years. From Hi-Fi to public address, portable loudspeakers and big concert systems.

GTR Direct is a proud dealer for RCF Canada
RCF Canada
Weight 54.01 lbs
Dimensions 22.4 × 18.27 × 28.11 in
