RCF NX 45-A 15″ woofer 133 DB SPL MAX

(1 customer review)

The RCF NX 45-A 15″ woofer 133 DB SPL MAX is an active speaker specifically designed to be the everyday tool for rental companies and professional musicians. It’s one of the most flexible speaker for deploying high-power and pristine sound as a stand-alone FOH system.

$3,299.00

UPC: 8024530015329 SKU: RCF-NX 45-A Category: Tags:
RCF Canada

Features of the RCF NX 45-A 15″ woofer 133 DB SPL MAX:

  • 1400 W 2-way class-D amplifier
  • 133 dB SPL Max
  • 45 – 20000 Hz Frequency Range
  • 90° x 50° constant directivity coverage
  • 15″ neodymium woofer, 3.5″ voice coil
  • Horn loaded 4.0”neodymium c. driver
  • Multiple rigging points
Specifications

Acoustical specifications
FREQUENCY RESPONSE:
45 Hz ÷ 20000 Hz

MAX SPL @ 1M:
133 dB

HORIZONTAL COVERAGE ANGLE:
90°

VERTICAL COVERAGE ANGLE:
50°
Transducers
COMPRESSION DRIVER:
1.4” neo, 4.0” v.c

WOOFER:
15” neo, 3.5” v.c
Input/Output section
INPUT SIGNAL:
bal/unbal

INPUT CONNECTORS:
XRL, Jack

OUTPUT CONNECTORS:
XLR

INPUT SENSITIVITY:
-2 dBu/+4 dBu

MIC. INPUT SENSITIVITY:
-32 dBu
Processor section
CROSSOVER FREQUENCIES:
650 Hz

PROTECTIONS:
Thermal, RMS

LIMITER:
Soft Limiter

CONTROLS:
Volume, Boost, Mic/Line
Power section
TOTAL POWER:
1400 W Peak, 700 W RMS

HIGH FREQUENCIES:
400 W Peak, 200 W RMS

LOW FREQUENCIES:
1000 W Peak, 500 W RMS

COOLING:
Convection

CONNECTIONS:
Powercon IN/OUT
Standard compliance
CE MARKING:
Yes
Physical specifications
CABINET/CASE MATERIAL:
Baltic birch plywood

HARDWARE:
5 x M10, 4 x quick lock

HANDLES:
2 Side

POLE MOUNT/CAP:
Yes

GRILLE:
Steel

COLOR:
Black
Size
HEIGHT:
707 mm / 27.83 inches

WIDTH:
418 mm / 16.46 inches

DEPTH:
402 mm / 15.83 inches

WEIGHT:
24 kg / 52.91 lbs

Brand

RCF

SINCE 1949 RCF BEGAN PRODUCING TRANSDUCERS IN 1949.
The first products sold were microphones and loudspeakers. In the late ’60s, concert sound was going electric, and many loudspeaker pioneers were searching for high-powered devices to use in their designs. RCF was one of the first European OEM suppliers for international brands, thanks to the company’s experience gained building high power transducers. In-depth know-how in transducers and electronics provided the perfect technological culture to allow RCF to develop complete pro audio systems, bringing the company to a leading position in multiple audio markets over the years. From Hi-Fi to public address, portable loudspeakers and big concert systems.

GTR Direct is a proud dealer for RCF Canada
RCF Canada
Weight 59.52 lbs
Dimensions 18.11 × 18.9 × 29.92 in
