Turbosound TCS110B Band Pass Subwoofer

(1 customer review)

The Turbosound TCS110B Band Pass Subwoofer – is a compact 1,200 Watt subwoofer designed to be used in a variety of installed sound system applications ranging from clubs and wine bars to theatres, themed environments and places of worship.


UPC: 4033653102216 SKU: TS-TCS110B Category: Tags:
Turbosound Canada

Features of the Turbosound TCS110B Band Pass Subwoofer

  • Band pass subwoofer for installation applications
  • 300 Watts continuous, 1,200 Watts peak power
  • HIgh excursion 10″ low frequency driver with inside/outside wound coil
  • Low distortion dual port design for maximum sound pressure level
  • 15 mm (5/8) birch plywood enclosure with hard wearing semi matt black paint finish
  • Integral M10 rigging points for ease of installation
  • Neutrik speakON* NL4 and barrier strip connectors
  • 10-Year Warranty Program*
  • Designed and engineered in the U.K.



Frequency Response 50 Hz – 150 Hz ±3 dB
40 Hz – 200 Hz -10 dB
Nominal Dispersion Half space
Power Handling (IEC) 300 W continuous, 1200 W peak
Sensitivity 94 dB (1 W @ 1 m)
Maximum SPL 119 dB continuous, 125 dB peak
Impedance 8 O
Components 1 x 10″ (262 mm) LF driver
Connectors 1 x Neutrik speakON* NL4
1 x barrier strip terminals
Dimensions (H x W x D) 330 x 585 x330 mm (13.0 x 23.0 x 13.0″)
Net Weight 15.8 kg (34.8 lbs)
Construction 15 mm (5/8″) birch plywood
Finish Semi matt black paint
Grille Powder-coated perforated steel
Flying Hardware M10 x 8




For over 40 years Turbosound has repeatedly shown award-winning innovation and leadership in the world of high end professional audio, producing landmark products that have defined and shaped the live industry.
