December 10, 2021Features of the Turbosound TCS218B-R Front Loaded Subwoofer
- Dual front loaded subwoofer for installation applications
- 1,600 Watts continuous, 6,400 Watts peak power
- All components weather resistant to IP54 for outdoor use
- Double suspension 18″ low frequency drivers with inside/outside wound coils
- Low distortion bass reflex port design
- 18 mm (3/4?) birch plywood enclosure with hard wearing semi matt black paint finish
- Architecturally styled powder coated perforated plated steel mesh grille with foam backing
- Multiple internal rigging points allow secure mounting for installation
- Captive cable tail with sealed cable gland on aluminium connector panel
- 10-Year Warranty Program*
- Designed and engineered in the U.K.
Specifications
System
Frequency Response | 33 Hz – 200 Hz ±3 dB 27 Hz – 200 Hz -10 dB |
Nominal Dispersion | Half space |
Power Handling (IEC) | 1600 W continuous, 6400 W peak |
Sensitivity | 99 dB (1 W @ 1 m) |
Maximum SPL | 131 dB continuous, 137 dB peak |
Impedance | Parallel: 4 O Discrete: 8 O x 2 |
Components | 2 x 18″ (460 mm) LF driver |
Enclosure
Connectors | 4-core captive cable tail |
Wiring | |
Dimensions HWD | 710 x 1130 x 730 mm (28.0 x 44.5 x 28.8″) |
Net Weight | 94 kg (207.2 lbs) |
Construction | 18 mm (5/8″) birch plywood |
Finish | Semi matt black paint |
Grille | Powder-coated perforated steel |
Flying Hardware | M10 x 8 |
