December 13, 2021Features of the Turbosound TLX212L Subwoofer
- Compact bandpass loaded subwoofer for portable and fixed installation applications
- 800 Watts continuous, 3,200 Watts peak power
- Ideal for FOH applications and compact drum, DJ or side fill monitoring
- Dual high excursion 12″ low frequency drivers with inside/outside wound coil for high power
- Integral rigging system for suspending or ground stacking with TLX43
- Low distortion bandpass port design
- 15 mm (5/8″) plywood enclosure with hard wearing semi matt black paint finish
- Powder coated perforated steel mesh grille
- Neutrik speakON* NL4 connectors for reliable long life operation
- 10-Year Warranty Program*
- Designed and engineered in the U.K.
Specifications
System
Frequency Response | 49 Hz – 173 Hz ±3 dB 38 Hz – 213 Hz -10 dB |
Nominal Dispersion | Half space |
Power Handling (IEC) | 800 W continuous, 3,200 W peak |
Sensitivity | 98 dB (1 W @ 1 m) |
Maximum SPL | 127 dB continuous, 133 dB peak |
Impedance | 8 O |
Components | 2 x 12″ (305 mm) LF driver |
Enclosure
Connectors | 2 x Neutrik speakON* NL4 |
Wiring | Pins 1+ / 1- input, pins 2+ / 2- link |
Dimensions H x W x D | 488 x 576 x 542 mm (19.2 x 22.7 x 21.3″) |
Net Weight | 43.0 kg (94.8 lbs) |
Construction | 15 mm (5 / 8″) plywood |
Finish | Semi matt black paint |
Grille | Powder coated perforated steel |
Suspension Hardware | Integral |
Accessories
TLX212L-WHB wheel board TLX43-FLB fly bar |
