December 13, 2021Features of the Turbosound TPZ153/64 Full Range Loudspeaker:
- Arrayable 3 way full range loudspeaker for installation applications
- Rotatable waveguide with 60 H x 40 V dispersion
- 850 Watts continuous, 3,400 Watts peak power
- Carbon fibre loaded 15″ low frequency driver with inside/outside wound coil
- Carbon fibre loaded 8″ high sensitivity mid range driver
- Titanium dome 1.4″ neodymium motor compression driver
- Multiple array configurations for extended coverage
- Switchable passive/bi-amp/tri-amp operation for flexibility of use
- Trapezoidal cabinet shape enables visually unobtrusive loudspeaker arrays
- Multiple internal rigging points allow bracket mount and suspension in any orientation
- 15 mm (5/8″) birch plywood enclosure with hard wearing semi matt black paint finish
- Architecturally styled powder coated perforated steel mesh grille
- Neutrik speakON* NL4 and barrier strip connectors
- 10-Year Warranty Program*
- Designed and engineered in the U.K.
Specifications
System
Frequency response | 45 Hz – 20 kHz ±3 dB 38 Hz – 20 kHz -10 dB |
Nominal dispersion | 60° H x 40° V @ -6 dB points |
Directivity Factor (Q) | 18.3 |
Directivity Index (DI) | 12.6 |
Power Handling (IEC) | |
Sensitivity | LF: 97 dB (1 W @ 1 m) MF: 107 (1 W @ 1 m) HF: 109 (1 W @ 1 m) |
Maximum SPL | |
Impedance | |
Crossover Type | Bi-amp / tri-amp switchable |
Components | 1 x 15″ (394 mm) LF driver 1 x 8″ (200 mm) MF driver 1 x 1.4″ (36 mm) HF compression driver |
Enclosure
Connectors | 2 x Neutrik speakON* NL4 2 x barrier strip terminals |
Wiring | |
Dimensions (H x W x D) | 967 x 559 x 656 mm (38.0 x 22.0 x 25.8″) |
Net Weight | 43.3kg (95 lbs) |
Construction | 15 mm (5/8″) birch plywood |
Finish | Semi matt black paint |
Grille | Powder coated perforated steel |
Flying Hardware | M10 x 13 points |
Accessories
TPZ153-FK |
