Chauvet DJ Wash FX Hex Effect Light

Brilliance, brightness and versatility are packed inside this powerhouse multi-purpose effect light that packs a punch with hex colour (RGBAW+UV) LEDs. Wash FX Hex functions as a chase effect, blinder, or a wash light.

chauvet dj logo

Features of the Chauvet DJ Wash FX Hex Effect Light:

Multi-purpose effect light functions as chase effect, blinder, or a wash light
Generate a broad spectrum of colours and achieve natural-looking colour temperatures with Hex colour LEDs
Advanced master/slave feature allows you to mirror effect between units
Use as a regular wash light or eye-candy effect with 6 chasing zones
Multiple control options include stand-alone, DMX, IR, or master/slave
Compatible with the IRC6 wireless remote for wireless triggering
Power linking saves time running cables
Fits best in the CHS-40 VIP gear bag


DMX Channels: 3, 6, 11 or 40
DMX Connectors: 3-pin XLR
Light Source: 18 LEDs (hex-colour RGBAW+UV) 8 W, 2.8 A, 50,000 hours life expectancy
Strobe Rate: 0 to 24 Hz
Beam Angle: 41°
Field Angle: 68°
Illuminance: 2,422 lux @ 2 m
Power Linking: 3 units @ 120 V; 5 units @ 230 V
Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
Power and Current: 200 W, 2.5 A @ 120 V, 60 Hz
194 W, 1.5 A @ 230 V, 50 Hz
Weight: 7.0 lbs (3.2 kg)
Size: 11.2 x 6.3 x 13 in (285 x 160x 330 mm)
Approvals: CE
Optional Controllers: IRC-6


Wash FX Hex
Power Cable
Quick Reference Guide


Chauvet DJ

CHAUVET DJ is a premier line of entertainment lighting, controllers and accessories for the mobile performer, DJs, clubs, corporate events and more. Offering the most value in the industry. Chauvet is a leading developer of luminaires, trussing, controllers, atmospherics and related equipment marketed globally under four main brands: CHAUVET DJ, CHAUVET Professional, Iluminarc, and ChamSys. Each Chauvet brand is well thought out to serve different customer needs but they all share the company’s focus on positively impacting every market segment with a competitive advantage in terms of value, innovation or performance.

Founded in 1990 by Albert and Berenice Chauvet, the company is widely recognized for its leadership in bringing successful concepts to market, including pioneering the development of affordable LED color mixing fixtures. The Chauvet mission is to elevate the world of lighting with customer-driven products at unparalleled value. We achieve this by following our VIP standards (value, innovation, performance) which motivate us to capture every technological and competitive edge to benefit our customers who are always our first priority.
