The Q-SYS AD-C10T-HPZB is a 10-in high-power, two-way full-range ceiling-mount loudspeaker with a coaxial compression driver that expands the Q-SYS portfolio to enable a broad range of high-fidelity applications across hospitality, entertainment and beyond.

$2,445.00
Tags: Category: SKU: AD-C10T-HPZB-W
Brand:

Features of the 10-Inch Mount Ceiling Speakers:

  • Zero bezel design for the needs of modern applications
  • Consistent tonal characteristics across the entire AcousticDesign Series for surface, ceiling, and pendant applications
  • DMT (Directivity Matched Transition) waveguide ensures smooth, uniform frequency response over the coverage area
  • Snap-fit magnetic grille
  • 3x double stepped, long travel dog-ear blind mount system
  • Intrinsic Correction voicings available via the Q-SYS Platform including CX-Q amplifiers
  • Blemish-free removable logo
  • Removable conduit cover plate, also available as accessory for pre-install wiring
  • UL1480 and UL2043 certified
  • Available in white (RAL 9003)
  • Complete EASE, CF2, CAD, & BIM information available online

Specifications:

  • LF transducer: 10 in (254 mm), 2.0 in. (50.8 mm) voice coil, ferrite
  • Enclosure configuration: Two-way, ceiling loudspeaker, Sealed
  • Coverage: 90° conical DMT
  • System bandwidth
  • -3 dB: 86 Hz – 20 kHz
  • -6dB: 76 Hz-20 kHz
  • -10 dB: 68 Hz-20 kHz
  • Sensitivity: 92.5 dB @ 1 W/ 1 m
  • Maximum SPL (continuous): 116 dB
  • Maximum SPL (peak): 128 dB
  • Maximum SPL (calculated): 122 dB
  • Power rating: Continuous power 250 W @ 8Ω, rated Power 500 W
  • Bypass impedance: 8 Ω
  • Minimum impedance: 6.9 Ω @ 20 hz
  • Taps (70v/100v): 25 W, 50 W, 100 W, 200 W / 50 W, 100 W, 200 W
  • Enclosure material: ABS baffle on powder coated steel backcan
  • Enclosure color: Black back-can, white grille (RAL 9010)
  • Connectors: 4-pin 0.2 in (5 mm) Euroblock connector with parallel output
  • Cutout dimension: Ø12 in (Ø305 mm)
  • Dimensions (HxWxD): 13.5 x 13.5 x 13.75 in (342.9 x 342.9 x 349.25 mm)
  • Weight: 23 lb (10.5kg)
