Q-SYS AC-S6TW 6in Surface Mount Speaker (Pair) – White

Name: Q-SYS AC-S6TW 6in Surface Mount Speaker (Pair) - White
SKU: AC-S6TW
Availability: InStock

NEW

Q-SYS AC-S6TW 6in Surface Mount Speaker (Pair) - White - Image 2

The white AcousticCoverage Series QSC AC-S6T is a pair of transformer-equipped 6.5″ surface-mount loudspeakers voiced to deliver enhanced clarity in the vocal range, making them suitable for 70/100V or 8-ohm operation in a variety of paging, A/V conferencing, and background music applications.

$584.00

UPC: 684284066831UPC: 684284066831

Tags: 6in High quality Mount Speaker Q-SYS WhiteCategory: Ceiling SpeakersSKU: AC-S6TW

Brand: Q-SYS

Description
Reviews 0

Features of the 6in Surface Mount Speaker:

High quality transducers provide exceptional clarity through the critical voice range.
Improved musicality often not seen in typical BGM class products.
Ported baffle for increased low frequency extension down to 70 Hz.
Low saturation 70/100V transformers with 8 ohm bypass.
4-pole Euroblock connector eases system wiring.
Advanced voicing via QSC Intrinsic Correction™, applied using Q-SYS processing or CXD amplifier platforms.
Available in black (RAL 9011) or white (RAL 9010).
Complete EASE, CAD & BIM information available online.

Specifications:

Effective frequency range: 60 Hz–20 kHz
Rated noise power / voltage: 30 watts / 15.5 volts rms
Broad-band sensitivity: 86 dB SPL
Coverage angle (-6 dB): 130° conical (500 Hz–5 kHz)
Directivity factor (Q): 6
Directivity Index: 8 dB
Maximum continuous SPL: 101 dB
Maximum peak SPL: 107 dB
Rated impedance: 8 ohms
Recommended amplifier power: 60 watts into 8 ohms
Transformer taps
70V: 30, 15, 7.5, 3.7, 1.9 watts
100V: 30, 15, 7.5, 3.8 watts
8 ohm bypass
LF transducer: 165 mm (6.5 in) Polypropylene woofer with 25 mm (1 in) voice coil
HF transducer: 25 mm (1 in) Aluminium dome tweeter with 25 mm (1 in) voice coil
Input connector type: Euroblock connector with parallel output
Enclosure material: UV treated, high impact ABS polymer
Grille material: Powder coated steel
Yoke material: Powder coated steel with brass inserts
Enclosure Details
Ingress protection: IP-44
Operating environment: Designed for indoor use
Operating Temperature Range: -20 to 50° C (-4 to 122° F)
Product Dimensions (HWD) inches: 11.9 x 8.5 x 7.8
Product Dimensions (HWD) mm: 303 × 215 × 197
Net Weight: 8.3 lb / 3.8 kg
Shipping weight: 8.4 kg (18.6 lb) pair packed
Shipping Dimensions (HWD) inches: 14.1 × 10.5 × 18.5 pair packed
Shipping Dimensions (HWD) mm: 359 x 267 x 470 pair packed
Included accessories: Yoke mount system, euroblock connector
