Q-SYS Collaboration Bundle Licence – Core 8Flex/Nano (Perpetual)

Features of the Bundle Licence:

• Expanded AEC Processing: Doubles the Acoustic Echo Cancellation (AEC) processors from 8 to 16, improving audio clarity in conferencing applications.
• Increased Softphones: Increases the number of supported Softphones from 2 to 4, facilitating multiple concurrent VoIP connections.
• Enhanced NM-T1 Microphone Support: Supports up to 6 NM-T1 microphones, doubling the capacity from the standard 3, allowing for more extensive microphone coverage in larger spaces.
• Additional DSP Processing Power: Approximately doubles the general-purpose DSP processing capacity, enabling more complex audio processing tasks.
• Expanded Networked Audio Channels: Increases Q-LAN/AES67 network channels from 64×64 to 128×128, accommodating more audio sources and destinations.

Specifications:

• License Type: Perpetual, Node Locked
• Applicable Hardware: Q-SYS Core Nano, Core 8 Flex
• Supported Q-SYS Designer Software Version: v9.3.0 or higher
• Q-LAN/AES67 Network Channels: 128 x 128 (expanded from 64 x 64)
• DSP Processing Power: Approximately 2x increase from standard
• Softphones: 4 (increased from 2)
• AEC Processors @ 200 ms: 16 (increased from 8)
• NM-T1 Microphone Support: Up to 6 (increased from 3)
