Q-SYS unDX4I 4×2 mic/line I/O Dante Wall Plate
NEW
Attero Tech unDX2IO+ is a versatile Dante network audio interface designed to seamlessly integrate analog audio equipment into Dante or AES67 audio networks.
$1,739.00
Features of the Wall Plate:
- Two balanced mic/line XLR inputs with software-selectable gain settings (-18 dB, -3 dB, +25 dB, +40 dB)
- Two balanced XLR line outputs with automatic muting on loss of Dante signal
- Additional two balanced line inputs on de-pluggable connectors
- 802.3af compliant PoE powered for single-cable connectivity
- +48V phantom power per channel, software selectable
- Compatible with Dante Domain Manager™
- Compact form factor suitable for standard dual-gang US junction boxes
Specifications:
- Audio Inputs: 2x XLR (balanced and RF filtered)
- Input Gain: -18 dB, -3 dB, +25 dB, +40 dB (software selectable)
- Phantom Power: +48V, software selectable
- Audio Outputs: 2x balanced line level on XLR connectors
- Maximum Output Level: +20 dBu
- Dante Network: Standard Ethernet, single RJ-45 connector, 100 Mbps, supports 44.1 kHz and 48 kHz sample rates
- Power: 802.3af PoE powered
- Dimensions (H x W x D): 4.2 x 3.5 x 2 inches (114.3 x 88.9 x 50.8 mm)
- Weight: 0.6 lbs (0.27 kg)
