Chauvet Pro Maverick Silens 2X Profile

Completely fanless operation makes this totally silent fixture ideal for the most demanding theatre and studio applications. Featuring dual gobo wheels (rotating + static), variable CMY + CTO and a full effects wheelhouse. Control via Art-Net, sACN, DMX, RDM or CRMX.

Features of the Chauvet Pro Maverick Silens 2X Profile

• Completely silent, fully featured 760 W 94+ CRI LED yoke profile fixture including CMY+CTO color mixing, a four-blade framing shutter system with rotation, a color wheel, animation wheel, a 10:1 zoom, prism, variable frost, as well as static and rotating gobo wheels.
• 100% convection cooled for zero fan noise along with silent motion and effects
• 16-bit dimming with selectable red shift of master dimmer for smooth control of fades
• Variable CMY + CTO color mixing system to create a wide pallet of colors
• One rotating and one static gobo wheel with unique, theatrical based designs
• Interchangeable gobos between rotating and static wheels
• Variable frost system
• + or – 60 degrees rotation framing shutter system to allow for better framing positioning.
• Animation wheel for enhanced visual effects
• Iris for total beam control
• RDM control over DMX for fixture reporting
• 5.5° to 57.9° zoom angle for variable beam sizes
• True 1 compatible power input and throughput
• Battery backup display with auto-rotate depending on fixture orientation

Specifications

Optical

• Light Source: 1 LEDs (CW) 750 W, (12 A), 6331 K, 30,000 hours life expectancy
• Light Source: 1 LED (RGB) 13 W, (3.7 A), 50,000 hours life expectancyColor Temperature (at full): 6317 K
• Color Temperature (at full): 6317 K
• CRI: 94.8
• TM-30 Rf: 93.2
• TM-30 Rg: 101.5
• Front Lens Diameter: 138mm
• Beam Angle: 5.5° to 49.9°
• Field Angle: 6° to 53.1°
• Zoom Range: 5° to 58°
• Cutoff Angle: 6.2° to 57.9°
• Zoom Range: 5.5° to 57.9°
• Lumens – Output: 12,748
• Illuminance (5.5°): 30,672 lux @ 5 m
• Illuminance (57.9°): 697 lux @ 5 m
• Selectable PWM: 20,000, 40,000

Dynamic Effects

• Pan and Tilt: 540°/270°
• Pan and Tilt Ranges: 540°, 360°, 180° pan/270°, 180°, 90° tilt
• Colors: 6 + white, split colors, continuous scroll at variable speeds
• Colors: CMY flags, CTO flag, color correction
• Gobos (1): 7 + open (7 glass), rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds
• Gobos (2): 8 + open (8 glass), continuous scroll at variable speeds
• Gobo Size: Gobo Wheel 1 (rotating): 26.9 mm (outside), 22 mm (image)
• Gobo Size: Gobo Wheel 2: 26.9 mm (outside), 22 mm (image)
• Effect Wheel: 1 effect
• Framing Shutters: Yes
• Dimmer: Electronic
• Shutter/Strobe: Electronic
• Zoom: Motorized
• Focus: Motorized
• Frost: Variable Frost – Motorized
• Iris: Motorized – 15 Leaf
• Prism: 5 Facets, round, motorized, rotating
• Strobe Rate: 0 to 20 Hz
• Move-in-Black: Yes
• Dim Curves: 4

Construction / Physical

• Dimensions: 17.0 x 10.8 x 31.1 in (433 x 276 x 792 mm)
• Weight: 75.5 lb. (34.4 kg)
• Exterior Color: Black
• Housing Material: High-impact flame-retardant Polymer

Connections

• Power Connection: Edison plug to Seetronic Powerkon IP65
• Power Input: Seetronic Powerkon IP65
• Data Connectors: 5-pin XLR, Amphenol XLR Net RJ45 connectors in/out
• Cable Length (power): 5 ft (1.5 m)

Control

• Control Protocol: Art-Net, DMX, CRMX, RDM, sACN
• DMX Channels: 32, 33, 41 or 42
• Art-Net Channels: 32, 33, 41 or 42
• Modes/Personalities: 4 personalities (32, 33, 41, and 42)

Electrical

• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power Linking: 2 units @ 100 V; 2 units @ 120 V; 4 units @ 208 V; 4 units @ 230 V; 4 units @ 240 V
• Power and Current: 650 W, 6.53 A @ 100 V, 60 Hz
• Power and Current: 640 W, 5.45 A @ 120 V, 60 Hz
• Power and Current: 639 W, 3.10 A @ 208 V, 60 Hz
• Power and Current: 648 W, 2.82 A @ 230 V, 50 Hz
• Power and Current: 654 W, 2.75 A @ 240 V, 50 Hz

Certifications / Qualifications

• CE, MET, FCC
• IP Rating: IP20, dry location
• Temperature (Ambient): -4 °F to 113 °F (-20 °C to 45 °C)

What’s Included

• Maverick Silens 2 Profile
• Seetronic Powerkon IP65 power cord
• 2 Omega brackets with mounting hardware
• Gel Frame Holder and Gel Frame
