NovaStar H5 All-In-One Splicer and Controller

Features of the NovaStar H5 All-In-One Splicer and Controller:

Modular and plug-in design, free combination at your will

• Two kinds of LED 4K sending cards
  – H_20xRJ45 sending card loads up to 13,000,000 pixels.
  – H_16xRJ45+2xfiber sending card loads up to 10,400,000 pixels and provides two OPT ports that copy the outputs on Ethernet ports.
• Multi-capacity configuration on a single card slot
  – 4x 2K—1K@60Hz
  – 2x 4K—1K@60Hz
  – 1x 4K—2K@60Hz
• Simple screen configuration using a single card and connector
• Online status monitoring of all input and output cards
• Hot-swappable input and output cards
• H_2xRJ45 IP input card supports up to 100 IP camera inputs and input mosaic.
• Auto decryption of HDCP-encrypted sources
• Decimal frame rates supported
• HDR10 and HLG processing

Specifications:

• Inputs cards available:

• 4x DVI card

• 4x HDMI card (2x HDMI 1.3 + 2x HDMI 1.4a)

• 1x HDMI 2.0 + 1x DP 1.2 card (Only one connector can be used at a time)

• 2x RJ45 Gigabit Ethernet card

• 4x 3G-SDI card

• 1x 12G SDI IN + 1x 12G SDI Loop

• Analog (VGA) card

• 2x DP1.1 card

• 1x HDMI 2.0

• 2x HDMI 2.0

• Output Cards:

• Monitor output (MVR) card with 2x RJ45 Gigabit ethernet and 1x HDMI 1.3 monitor output

• 16x RJ45 + 2x Fiber output card. 10,400,000 pixels loading capacity per card with a max width of 10,240 pixels and a max height of 10,240 pixels

• 20x RJ45 output card. 13,000,000 pixels loading capacity per card with a max width of 10,752 pixels and a max height of 10,752 pixels
