RCF P 2110T 10″ woofer 1″ c. driver

Features of the RCF P 2110T 10″ woofer 1″ c. driver:

• 124 dB SPL Max, 200W RMS
• Weatherproof IP55 cabinet with UV protection
• Line transformer
• 90° x 40° CMD constant directivity horn
• 10″ high-output LF transducer with 2.5″ voice coil
• RCF Precision 1″ C. Driver with 1.5″ voice coil
• 12 brass suspension points (M10)
• Rotomolded single piece cabinet

Specifications:

FREQUENCY RESPONSE (-10DB):
95 Hz ÷ 20000 Hz

MAX SPL @ 1M:
124 dB

HORIZONTAL COVERAGE ANGLE:
90°

VERTICAL COVERAGE ANGLE:
40°

DIRECTIVITY INDEX Q:
11

SYSTEM SENSITIVITY:
95 dB
Power section
NOMINAL IMPEDANCE (OHM):
16 ohm

POWER HANDLING:
200 W RMS

PEAK POWER HANDLING:
800 W PEAK

RECOMMENDED AMPLIFIER:
400 W

PROTECTIONS:
Dynamic active mosfet

CROSSOVER FREQUENCIES:
2000 Hz
Transducers
COMPRESSION DRIVER:
1.0”, 1.5” v.c

NOMINAL IMPEDANCE (OHM):
8 ohm

INPUT POWER RATING:
25 W AES, 50 W PEAK

SENSITIVITY (DB, 1W @ 1M):
106 dB, 1W @ 1m

WOOFER:
Coaxial 10”, 2.5” v.c

NOMINAL IMPEDANCE (OHM):
16 ohm

INPUT POWER RATING:
180 W AES, 360 W PEAK

SENSITIVITY (DB, 1W @ 1M):
95 dB, 1W @ 1m
Input/Output section
INPUT CONNECTORS:
Neoprene Cable

CONSTANT VOLTAGE TRANSFORMER:
100 V

POWER SELECTION 1 (100 V):
60 W – 167 ohm

POWER SELECTION 2 (100 V):
30 W – 333 ohm

POWER SELECTION 3 (100 V):
15 W – 667 ohm
Standard compliance
IP PROTECTION GRADE:
IP 55

CE MARKING:
Yes
Physical specifications
COLOR:
Grey

HARDWARE:
12 x M8 inserts + U-brackets and pair of spacers

GRILLE:
Aluminum with waterproof clothing

CABINET/CASE MATERIAL:
PE Low Density
Size
WIDTH:
350 mm / 13.78 inches

DEPTH:
320 mm / 12.6 inches

HEIGHT:
350 mm / 13.78 inches

WEIGHT:
13.4 kg / 29.54 lbs
