RCF P 3115T 15″ woofer 1.3″ c. driver

Features of the RCF P 3115T 15″ woofer 1.3″ c. driver:

• 129 dB SPL Max, 300W RMS
• Weatherproof IP55 cabinet with UV protection
• Line Transformer
• 90° x 60° CMD constant directivity horn
• 15″ high-output LF transducer with 3″ voice coil
• RCF Precision 1.3″ C. Driver with 2.5″ voice coil
• 12 brass suspension points (M10)
• Rotomolded cabinet available in white or black

Specifications:

FREQUENCY RESPONSE (-10DB):
75 Hz ÷ 20000 Hz

MAX SPL @ 1M:
129 dB

HORIZONTAL COVERAGE ANGLE:
90°

VERTICAL COVERAGE ANGLE:
60°

DIRECTIVITY INDEX Q:
13

SYSTEM SENSITIVITY:
98 dB
Power section
NOMINAL IMPEDANCE (OHM):
16 ohm

POWER HANDLING:
300 W RMS

PEAK POWER HANDLING:
1200 W PEAK

RECOMMENDED AMPLIFIER:
600 W

PROTECTIONS:
Dynamic active mosfet

CROSSOVER FREQUENCIES:
1300 Hz
Transducers
COMPRESSION DRIVER:
1.0”, 1.5” v.c

NOMINAL IMPEDANCE (OHM):
8 ohm

INPUT POWER RATING:
25 W AES, 50 W PEAK

SENSITIVITY (DB, 1W @ 1M):
108 dB, 1W @ 1m

WOOFER:
Coaxial 15”, 2.5” v.c

NOMINAL IMPEDANCE (OHM):
16 ohm

INPUT POWER RATING:
250 W AES, 500 W PEAK

SENSITIVITY (DB, 1W @ 1M):
98 dB, 1W @ 1m
Input/Output section
INPUT CONNECTORS:
Neoprene Cable

CONSTANT VOLTAGE TRANSFORMER:
100 V

POWER SELECTION 1 (100 V):
120 W – 83 ohm

POWER SELECTION 2 (100 V):
60 W – 167 ohm

POWER SELECTION 3 (100 V):
30 W – 333 ohm
Standard compliance
IP PROTECTION GRADE:
IP 55

CE MARKING:
Yes
Physical specifications
COLOR:
Grey

HARDWARE:
12 x M10 inserts + U-brackets and pair of spacers

GRILLE:
Aluminum with waterproof clothing

CABINET/CASE MATERIAL:
PE Low Density
Size
WIDTH:
463 mm / 18.23 inches

DEPTH:
433 mm / 17.05 inches

HEIGHT:
463 mm / 18.23 inches

WEIGHT:
18.4 kg / 40.57 lbs
