RCF P 6215 15″ woofer 2.5″ neodymium c. driver

Features of the RCF P 6215 15″ woofer 2.5″ neodymium c. driver:

• 134 dB SPL Max, 600W RMS
• Weatherproof IP55 cabinet with UV protection
• Rotomolded cabinet available in white or black
• 60° x 60° conical CMD horn
• One 15″ high-output neodymium LF transducer
• One RCF Precision 2.5″ neodymium C. Driver
• Active Mosfet Compression Driver Protection
• 12 brass suspension points (M10)

Specifications:

FREQUENCY RESPONSE (-10DB):
75 Hz ÷ 20000 Hz

MAX SPL @ 1M:
134 dB

HORIZONTAL COVERAGE ANGLE:
60°

VERTICAL COVERAGE ANGLE:
60°

DIRECTIVITY INDEX Q:
13

SYSTEM SENSITIVITY:
100 dB
Power section
NOMINAL IMPEDANCE (OHM):
8 ohm

POWER HANDLING:
600 W RMS

PEAK POWER HANDLING:
2400 W PEAK

RECOMMENDED AMPLIFIER:
1200 W

PROTECTIONS:
Dynamic active mosfet

CROSSOVER FREQUENCIES:
1100 Hz
Transducers
COMPRESSION DRIVER:
Coaxial 1.3” neo, 2.5” v.c

NOMINAL IMPEDANCE (OHM):
8 ohm

INPUT POWER RATING:
90 W AES, 180 W PEAK

SENSITIVITY (DB, 1W @ 1M):
108 dB, 1W @ 1m

WOOFER:
Coaxial 15” neo, 3.0” v.c

NOMINAL IMPEDANCE (OHM):
8 ohm

INPUT POWER RATING:
450 W AES, 900 W PEAK

SENSITIVITY (DB, 1W @ 1M):
101 dB, 1W @ 1m
Input/Output section
INPUT CONNECTORS:
Neoprene Cable
Standard compliance
IP PROTECTION GRADE:
IP 55

CE MARKING:
Yes
Physical specifications
COLOR:
Grey

HARDWARE:
12 x M10 + U-Bracket and Pair of spacers

GRILLE:
Aluminum with waterproof clothing

CABINET/CASE MATERIAL:
PE Low Density
Size
WIDTH:
463 mm / 18.23 inches

DEPTH:
433 mm / 17.05 inches

HEIGHT:
463 mm / 18.23 inches

WEIGHT:
17 kg / 37.48 lbs
