Elation DTW BLINDER 700 IP

(1 customer review)

The Elation DTW BLINDER 700 IP features (4) high powered 175W 2-in-1 Warm White/Amber COB LEDs, a wide 67° beam angle, full color temperature range control plus independent Dim-to-Warm channel control (1,800K – 3,200K), easily attachable 15° narrow beam filters (included).


UPC: 837874019827 SKU: DTW-BLINDER-700-IP Category: Tags:

Features of the Elation DTW BLINDER 700 IP

 IP65 Rated
Pixel Control
67° Wide Beam Angle
15° Narrow Beam Filters (included)
Independent Dim-to-Warm Channel Control (1,800K – 3,200K)
RDM (Remote Device Management)
Rugged Die-Cast Aluminum Exterior
Flicker Free Operation for TV and FILM


(4) 175W 2-in-1 Warm White/Amber COB LEDs
50,000 Hour Average LED Life*
*LED Life may vary depending on several factors including but not limited to:
Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.

7,719 LUX 717 FC (15° @ 9.8 ft / 3m w/Fresnel lens)
1,104 LUX 94 FC (67° @ 9.8 ft / 3m w/No Fresnel lens)

Pixel Control
15° Narrow Beam Angle with included Fresnel Lens
67° Wide Beam Angle with Fresnel Lens Removed
Unique Dim-to-Warm Channel Control (1,800K – 3,200K)
Independent Dimming of Each COB LED Module
Electronic Strobe and Variable Dimming Curves

Warm White / Amber

(9) DMX Channel Modes (13 Total Channels)
RDM (Remote Device Management)
4 Button Control Panel and LCD Menu Display
IP Rated 5pin DMX In/Out
powerCON TRUE1 In/Out
With Wired Digital Communication Network

Length: 15.7″ (400mm)
Width: 9.7 (244mm)
Horizontal Height: 16.1″ (410mm)
Weight: 28.0 lbs. (12.7 kg)

AC 100-240V – 50/60Hz
680W Max Power Consumption
Multiple Unit Power Linking
5°F to 113°F (-15°C to 45°C)

CE | cETLus | IP65


Elation professional

Elation professional offers the stage lighting industry the most complete toolbox of conventional and intelligent LED lighting, video, and atmospheric effect products specifically designed for the Theatrical and Concert Stage, Rental, Production, Studio, Broadcast, House of Worship, Corporate AV, Exhibition, Night Club, Leisure, Theme Park, and Cruise Ship markets.
