Elation DTW BLINDER 350 IP

(1 customer review)

The Elation DTW BLINDER 350 IP features (2) high powered 175W 2-in-1 Warm White / Amber COB LEDs, 65° wide beam angle, full color temperature range control plus independent Dim-to-Warm channel control (1,800K – 3,200K), easily attachable 15° narrow beam filters (included).

$1,889.00

UPC: 837874019810 SKU: DTW-BLINDER-350-IP Category: Tags:
Elation

Features of the Elation DTW BLINDER 350 IP

 IP65 Rated
Pixel Control
65° Wide Beam Angle
15° Narrow Beam Filters (included)
Independent Dim-to-Warm Channel Control (1,800K – 3,200K)
RDM (Remote Device Management)
Rugged Die-Cast Aluminum Exterior
Flicker Free Operation for TV and FILM

Specifications

SOURCE
(2) 175W 2-in-1 Warm White/Amber COB LEDs
50,000 Hour Average LED Life*
*LED Life may vary depending on several factors including but not limited to:
Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.

PHOTOMETRIC DATA (Full ON)
4,216 LUX 391.7 FC (15° @ 9.8 ft / 3m w/Fresnel lens)
593 LUX 51.1 FC (65° @ 9.8 ft / 3m w/No Fresnel lens)

EFFECTS
Pixel Control
15° Narrow Beam Angle with included Fresnel Lens
65° Wide Beam Angle with Fresnel Lens removed
Unique Dim-to-Warm Channel Control (1,800K – 3,200K)
Independent Dimming of Each COB LED Module
Electronic Strobe and Variable Dimming Curves

COLOR
Warm White / Amber

CONTROL / CONNECTIONS
(9) DMX Channel Modes (9 Total Channels)
RDM (Remote Device Management)
4 Button Control Panel and LCD Menu Display
IP Rated 5pin DMX In/Out
IP65 Locking Power Cable In/Out
With Wired Digital Communication Network

SIZE / WEIGHT
Length: 15.7″ (400mm)
Width: 9.5″ (241mm)
Horizontal Height: 9.6″ (245mm)
Weight: 18.0 lbs. (8.2 kg)

ELECTRICAL / THERMAL
AC 100-240V – 50/60Hz
310W Max Power Consumption
Multiple Unit Power Linking
5°F to 113°F (-15°C to 45°C)

APPROVALS / RATINGS
CE | cETLus | IP65
