RCF SUB 8004-AS 18″ Woofer 136 DB MAX SPL

(1 customer review)

The RCF SUB 8004-AS 18″ Woofer 136 DB MAX SPL is one of the most powerful 18” subwoofers in pro-sound category. Featuring a high power, hypervented 18” woofer, with 4” inside/outside voice coils, this cabinet is designed to deliver a serious amount of low frequency.

$5,534.00

UPC: 8024530010751 SKU: RCF-SUB 8004-AS Category: Tags:
RCF Canada

Features of the RCF SUB 8004-AS 18″ Woofer 136 DB MAX SPL:

  • 2500 Watt Peak, 1250 Watt RMS
  • 136 dB max SPL
  • 30 Hz – 120 Hz frequency response
  • 18″ Woofer, 4.0″ voice coil vented woofer
  • DSP controlled Input section with selectable presets
  • Delay control
  • Baltic birch tour grade cabinet
  • Compatible with NXL23-A (stacking)
  • Compatible with NXL24-A (stacking)
  • Multiple configurations with HDL 10-A and HDL 20-A
Specifications

Acoustical specifications
FREQUENCY RESPONSE:
30 Hz ÷ 120 Hz
Transducers
WOOFER:
18”, 4.0” v.c
Input/Output section
INPUT SIGNAL:
bal/unbal

INPUT CONNECTORS:
XLR

OUTPUT CONNECTORS:
XLR

INPUT SENSITIVITY:
-2 dBu/+4 dBu
Processor section
HI-PASS FREQUENCIES:
120 Hz

LOW-PASS FREQUENCIES:
90 Hz

PROTECTIONS:
Thermal, RMS

LIMITER:
Fast Limiter

CONTROLS:
Xover, Phase switch, Deep/Punch, Output Delay Settings, Cardioid
Power section
TOTAL POWER:
2500 W Peak, 1250 W RMS

LOW FREQUENCIES:
2500 W Peak, 1250 W RMS

COOLING:
Convection

CONNECTIONS:
Powercon IN/OUT
Standard compliance
CE MARKING:
Yes
Physical specifications
COLOR:
Black
Size
HEIGHT:
700 mm / 27.56 inches

WIDTH:
558 mm / 21.97 inches

DEPTH:
700 mm / 27.56 inches

WEIGHT:
56 kg / 123.46 lbs

Brand

RCF

SINCE 1949 RCF BEGAN PRODUCING TRANSDUCERS IN 1949.
The first products sold were microphones and loudspeakers. In the late ’60s, concert sound was going electric, and many loudspeaker pioneers were searching for high-powered devices to use in their designs. RCF was one of the first European OEM suppliers for international brands, thanks to the company’s experience gained building high power transducers. In-depth know-how in transducers and electronics provided the perfect technological culture to allow RCF to develop complete pro audio systems, bringing the company to a leading position in multiple audio markets over the years. From Hi-Fi to public address, portable loudspeakers and big concert systems.

GTR Direct is a proud dealer for RCF Canada
RCF Canada
Weight 132.28 lbs
Dimensions 24.09 × 29.57 × 29.96 in
